Hollyland

HOLLY FUSE H3BD630B 690V AC 630A aR Fuse

Name: HOLLY FUSE H3BD630B 690V AC 630A aR Fuse
Brand: Hollyland
SKU: H3BD630B

Part Number: H3BD630B

● Check availability

Manufacturer-verified specifications for HOLLY FUSE H3BD630B: 630A, 690V AC. Interrupting capacity: 200,000A at 690V AC. Confirmed approvals: CCC.

Rated Current630A

Rated Voltage690V AC

Breaking Capacity200,000A at 690V AC

PackageNH3

Tags

690V AC aR Bolt-Down fuse NH3 Very Fast Acting

HOLLY FUSE H3BD630B: aR semiconductor fuse, 630A, 690V AC. The catalog specifies 200,000a at 690v ac. Confirmed approvals: CCC. Standards: IEC 60269-4, GB/T 13539.4, UL 248-13. Manufacturer source: Powerfuse catalog page 65.

Technical Specifications

Part Number: H3BD630B
Manufacturer Part Number: H3BD630B
Series: H3BD
Fuse Type: Fuse
Current Rating: 630A
Voltage Rating: 690V AC
AC / DC: AC
Breaking Capacity: 200,000A at 690V AC
Package / Dimensions: NH3
Mounting: Bolt-Down
Application: Power Electronics
Standard: GB/T 13539.4 · IEC 60269-4 · UL 248-13
Terminal Type: Blade
Fuse Speed: Very Fast Acting
Utilization Class: aR
Approvals: CCC
Certifications: CCC
Reference Lead Time: 2–4 weeks
Rated current: 630A
Rated voltage: 690V AC
Interrupting capacity: 200,000A at 690V AC
Class of operation: aR
Confirmed approvals: CCC
Standards: IEC 60269-4, GB/T 13539.4, UL 248-13
Source: Hollyland Powerfuse catalog, page 65
