HOLLY FUSE H3BD500C 690V AC 500A aR Fuse

Hollyland

HOLLY FUSE H3BD500C 690V AC 500A aR Fuse

Part Number: H3BD500C

● Check availability

HOLLY FUSE H3BD500C combines a 500A current rating with 690V AC operation for demanding protection applications. Confirmed approvals: CCC.

Rated Current500A

Rated Voltage690V AC

Breaking Capacity200,000A at 690V AC

PackageNH3

Tags

690V AC aR Bolt-Down fuse NH3 Very Fast Acting

Part H3BD500C is a HOLLY FUSE H3BD-series aR semiconductor fuse with ratings of 500A, 690V AC. Confirmed approvals: CCC. Interrupting capacity: 200,000A at 690V AC. Standards: IEC 60269-4, GB/T 13539.4, UL 248-13. Technical data checked against catalog page 65.

Technical Specifications

Part Number: H3BD500C
Manufacturer Part Number: H3BD500C
Series: H3BD
Fuse Type: Fuse
Current Rating: 500A
Voltage Rating: 690V AC
AC / DC: AC
Breaking Capacity: 200,000A at 690V AC
Package / Dimensions: NH3
Mounting: Bolt-Down
Application: Power Electronics
Standard: GB/T 13539.4 · IEC 60269-4 · UL 248-13
Terminal Type: Blade
Fuse Speed: Very Fast Acting
Utilization Class: aR
Approvals: CCC
Certifications: CCC
Reference Lead Time: 2–4 weeks
Rated current: 500A
Rated voltage: 690V AC
Interrupting capacity: 200,000A at 690V AC
Class of operation: aR
Confirmed approvals: CCC
Standards: IEC 60269-4, GB/T 13539.4, UL 248-13
Source: Hollyland Powerfuse catalog, page 65
