Hollyland

HOLLY FUSE 5FF-080H 250V AC 8A Very Fast-Acting Ceramic Fuse

Name: HOLLY FUSE 5FF-080H 250V AC 8A Very Fast-Acting Ceramic Fuse
Brand: Hollyland
SKU: 5FF-080H

Part Number: 5FF-080H

● Check availability

HOLLY FUSE 5FF-080H combines its rated protection value with 250V AC operation in the 5FF product family.

Rated Current8A

Rated Voltage250V AC

Breaking Capacity1,500A at 250V AC

Package5.2×20mm

Tags

250V AC 5.2×20mm 5FF Ceramic Tube Fuse Very Fast Acting

Part 5FF-080H is a HOLLY FUSE 5FF-series very fast-acting ceramic fuse with specifications of 8A, 250V AC. Interrupting capacity: 1,500A at 250V AC. Standards: IEC 60127. Technical data checked against catalogue p41.

Technical Specifications

Part Number: 5FF-080H
Manufacturer Part Number: 5FF-080H
Series: 5FF
Fuse Type: Ceramic Tube Fuse
Current Rating: 8A
Voltage Rating: 250V AC
AC / DC: AC
Breaking Capacity: 1,500A at 250V AC
I²t: 16.69 A²s
Operating Temperature: -55°C to +125°C
Package / Dimensions: 5.2×20mm
Mounting: Cartridge / Clip
Application: Electronic Circuit Protection
Standard: IEC 60127
Terminal Type: Ferrule
Fuse Speed: Very Fast Acting
Reference Lead Time: 2–4 weeks
Rated current: 8A
Rated voltage: 250V AC
Fuse characteristic: Very Fast-Acting
Fuse construction: Ceramic Tube Fuse
Interrupting capacity: 1,500A at 250V AC
Standards: IEC 60127
Manufacturer approval note: No safety approval column is shown in the detailed product table.
Source: Hollyland Current Fuse catalogue, printed page 41
