HOLLY FUSE 2XLPV100U15D 1500V 100A Photovoltaic Fuse

Name: HOLLY FUSE 2XLPV100U15D 1500V 100A Photovoltaic Fuse
Brand: Hollyland
SKU: 2XLPV100U15D

Part Number: 2XLPV100U15D

● LT: 2-4w

HOLLY FUSE 2XLPV100U15D is a photovoltaic fuse rated 100A, 1500V in the NH2XLPV-C(D) series.

Rated Current100A

Rated Voltage1500V

Breaking Capacity50000A at 1500V DC

Tags

1500V DC Bolt-Down gPV Photovoltaic Fuses Very Fast Acting

HOLLY FUSE 2XLPV100U15D is a photovoltaic fuse in the NH2XLPV-C(D) series, rated 100A, 1500V. Standards: IEC 60269, UL 248. Approvals: UL Listed. Interrupting/breaking capacity: 50000A at 1500V DC.

Specifications

Type: Photovoltaic Fuses
Rated current type: DC
Standards also cited: IEC 60269-6, UL 248-19
Source: powerfuse catalogue page 44

Technical Specifications

Part Number: 2XLPV100U15D
Manufacturer Part Number: 2XLPV100U15D
Series: NH2XLPV-C(D)
Fuse Type: Photovoltaic Fuses
Current Rating: 100A
Voltage Rating: 1500V
AC / DC: DC
Breaking Capacity: 50000A at 1500V DC
Mounting: Bolt-Down
Application: Solar PV
Standard: IEC 60269 · UL 248
Terminal Type: Ferrule
Fuse Speed: Very Fast Acting
Utilization Class: gPV
Approvals: UL Listed
Certifications: UL Listed
Type: Photovoltaic Fuses; Rated current type: DC; Standards also cited: IEC 60269-6, UL 248-19; Source: powerfuse catalogue page 44
