HOLLY FUSE 2XLPV200U15C2 1500V 200A Photovoltaic Fuse

Name: HOLLY FUSE 2XLPV200U15C2 1500V 200A Photovoltaic Fuse
Brand: Hollyland
SKU: 2XLPV200U15C2

Part Number: 2XLPV200U15C2

● LT: 2-4w

Product data for HOLLY FUSE 2XLPV200U15C2 photovoltaic fuse: 200A, 1500V; approvals include UL Listed.

Rated Current200A

Rated Voltage1500V

Breaking Capacity50000A at 1500V DC

Tags

1500V DC Bolt-Down gPV Photovoltaic Fuses Very Fast Acting

HOLLY FUSE part 2XLPV200U15C2 is listed as a photovoltaic fuse with 200A, 1500V under the NH2XLPV-C(D) series. Standards: IEC 60269, UL 248. Approvals: UL Listed. Interrupting/breaking capacity: 50000A at 1500V DC.

Technical Specifications

Part Number: 2XLPV200U15C2
Manufacturer Part Number: 2XLPV200U15C2
Series: NH2XLPV-C(D)
Fuse Type: Photovoltaic Fuses
Current Rating: 200A
Voltage Rating: 1500V
AC / DC: DC
Breaking Capacity: 50000A at 1500V DC
Mounting: Bolt-Down
Application: Solar PV
Standard: IEC 60269 · UL 248
Terminal Type: Ferrule
Fuse Speed: Very Fast Acting
Utilization Class: gPV
Approvals: UL Listed
Certifications: UL Listed
Type: Photovoltaic Fuses; Rated current type: DC; Standards also cited: IEC 60269-6, UL 248-19; Source: powerfuse catalogue page 44
