HOLLY FUSE 10PV12U0 1000V 12A Photovoltaic Fuse

Name: HOLLY FUSE 10PV12U0 1000V 12A Photovoltaic Fuse
Brand: Hollyland
SKU: 10PV12U0

Part Number: 10PV12U0

● Check availability

10PV12U0 is part of the HOLLY FUSE HC10PV range, specified at 12A, 1000V.

Rated Current12A

Rated Voltage1000V

Breaking Capacity30000A at 1000V DC

Package10×38mm

Tags

10×38mm 1000V DC Bolt-Down gPV Photovoltaic Fuses Very Fast Acting

The HOLLY FUSE 10PV12U0 photovoltaic fuse carries 12A, 1000V and belongs to the HC10PV family. Standards: UL 248. Approvals: UL Listed. Interrupting/breaking capacity: 30000A at 1000V DC.

Specifications

Type: Photovoltaic Fuses
Rated current type: DC
Standards also cited: UL 248-19
Source: powerfuse catalogue page 28

Technical Specifications

Part Number: 10PV12U0
Manufacturer Part Number: 10PV12U0
Series: HC10PV
Fuse Type: Photovoltaic Fuses
Current Rating: 12A
Voltage Rating: 1000V
AC / DC: DC
Breaking Capacity: 30000A at 1000V DC
Package / Dimensions: 10×38mm
Mounting: Bolt-Down
Application: Solar PV
Standard: UL 248
Terminal Type: Ferrule
Fuse Speed: Very Fast Acting
Utilization Class: gPV
Approvals: UL Listed
Certifications: UL Listed
Type: Photovoltaic Fuses; Rated current type: DC; Standards also cited: UL 248-19; Source: powerfuse catalogue page 28
