HOLLY FUSE 10PV10U0 1000V 10A Photovoltaic Fuse

Name: HOLLY FUSE 10PV10U0 1000V 10A Photovoltaic Fuse
Brand: Hollyland
SKU: 10PV10U0

Part Number: 10PV10U0

● Check availability

HOLLY FUSE 10PV10U0 photovoltaic fuse – 10A, 1000V, HC10PV family.

Rated Current10A

Rated Voltage1000V

Breaking Capacity30000A at 1000V DC

Package10×38mm

Tags

10×38mm 1000V DC Bolt-Down gPV Photovoltaic Fuses Very Fast Acting

HOLLY FUSE 10PV10U0 is a photovoltaic fuse in the HC10PV series, rated 10A, 1000V. Standards: UL 248. Approvals: UL Listed. Interrupting/breaking capacity: 30000A at 1000V DC.

Specifications

Type: Photovoltaic Fuses
Rated current type: DC
Standards also cited: UL 248-19
Source: powerfuse catalogue page 28

Technical Specifications

Part Number: 10PV10U0
Manufacturer Part Number: 10PV10U0
Series: HC10PV
Fuse Type: Photovoltaic Fuses
Current Rating: 10A
Voltage Rating: 1000V
AC / DC: DC
Breaking Capacity: 30000A at 1000V DC
Package / Dimensions: 10×38mm
Mounting: Bolt-Down
Application: Solar PV
Standard: UL 248
Terminal Type: Ferrule
Fuse Speed: Very Fast Acting
Utilization Class: gPV
Approvals: UL Listed
Certifications: UL Listed
Type: Photovoltaic Fuses; Rated current type: DC; Standards also cited: UL 248-19; Source: powerfuse catalogue page 28
