What are the current and voltage ratings of 10aR2.5U6?

10aR2.5U6 is rated 2.5A at 690V AC/DC.

What is the breaking capacity of 10aR2.5U6?

10aR2.5U6 has a breaking capacity of 80,000A at 690V AC / 50,000A at 690V DC. Confirm this covers the available fault current at the installation point.

What package size does 10aR2.5U6 use?

10aR2.5U6 uses 10×38mm package size.

Which standards and approvals apply to 10aR2.5U6?

10aR2.5U6 is listed under GB/T 13539.4, IEC 60269-4, UL 248-13 / CCC · VDE · cURus.

What is 10aR2.5U6 used for?

10aR2.5U6 is listed for Power Electronics applications. Verify suitability for your circuit before ordering.

What are the ordering terms for 10aR2.5U6?

10aR2.5U6: typical lead time 2–4 weeks. Submit a quote request for a firm quotation.

Hollyland

HOLLY FUSE 10aR2.5U6 690V AC/DC 2.5A aR Fuse

Name: HOLLY FUSE 10aR2.5U6 690V AC/DC 2.5A aR Fuse
Brand: Hollyland
SKU: 10aR2.5U6

Part Number: 10aR2.5U6

● Check availability

Manufacturer-verified specifications for HOLLY FUSE 10aR2.5U6: 2.5A, 690V AC/DC. Interrupting capacity: 80,000A at 690V AC / 50,000A at 690V DC. Confirmed approvals: CCC, VDE, cURus.

Rated Current2.5A

Rated Voltage690V AC/DC

Breaking Capacity80,000A at 690V AC / 50,000A at 690V DC

Package10×38mm

Tags

HOLLY FUSE 10aR2.5U6: aR semiconductor fuse, 2.5A, 690V AC/DC. The catalog specifies 80,000a at 690v ac / 50,000a at 690v dc. Confirmed approvals: CCC, VDE, cURus. Standards: IEC 60269-4, GB/T 13539.4, UL 248-13. Manufacturer source: Powerfuse catalog page 85.
