What are the current and voltage ratings of 10aR2.5U5?

10aR2.5U5 is rated 2.5A at 500V AC/DC.

What is the breaking capacity of 10aR2.5U5?

10aR2.5U5 has a breaking capacity of 120,000A at 500V AC / 120,000A at 500V DC. Confirm this covers the available fault current at the installation point.

What package size does 10aR2.5U5 use?

10aR2.5U5 uses 10×38mm package size.

Which standards and approvals apply to 10aR2.5U5?

10aR2.5U5 is listed under GB/T 13539.4, IEC 60269-4, UL 248-13 / CCC · VDE · cURus.

What is 10aR2.5U5 used for?

10aR2.5U5 is listed for Power Electronics applications. Verify suitability for your circuit before ordering.

What are the ordering terms for 10aR2.5U5?

10aR2.5U5: typical lead time 2–4 weeks. Submit a quote request for a firm quotation.

Hollyland

HOLLY FUSE 10aR2.5U5 500V AC/DC 2.5A aR Fuse

Name: HOLLY FUSE 10aR2.5U5 500V AC/DC 2.5A aR Fuse
Brand: Hollyland
SKU: 10aR2.5U5

Part Number: 10aR2.5U5

● Check availability

10aR2.5U5 from HOLLY FUSE provides 2.5A, 500V AC/DC protection for power-conversion and industrial electrical systems. Confirmed approvals: CCC, VDE, cURus.

Rated Current2.5A

Rated Voltage500V AC/DC

Breaking Capacity120,000A at 500V AC / 120,000A at 500V DC

Package10×38mm

Tags

For applications requiring 2.5A, 500V AC/DC, HOLLY FUSE 10aR2.5U5 provides manufacturer-defined protection characteristics in the HC10aR series. Interrupting capacity: 120,000A at 500V AC / 120,000A at 500V DC. Standards: IEC 60269-4, GB/T 13539.4, UL 248-13. Confirmed approvals: CCC, VDE, cURus. Verified against the Hollyland Powerfuse catalog, page 85.
