Littelfuse FLQ025 25A 500V Time-Delay Midget Fuse

Littelfuse

Littelfuse FLQ025 25A 500V Time-Delay Midget Fuse

Part Number: FLQ025

● Contact for Availability

This Littelfuse time-delay midget fuse, part FLQ025, is rated 25A/500V AC and uses a 10×38mm package.

Rated Current25A

Rated Voltage500V AC

Breaking Capacity10kA

Package10×38mm

Tags

10×38mm 25A 500V FLQ Series FLQ025 Littelfuse time-delay

Within the FLQ Series, Littelfuse FLQ025 is specified for 25A service at 500V AC. With 38.1 × 10.31mm dimensions and a 10kA interrupting rating, the fuse suits the listed cartridge / clip mounting style. Typical applications include motor, transformer and control circuits; the product is listed to UL 248-14 with UL Listed, CSA, CE and RoHS approvals.

Technical Specifications

Part Number: FLQ025
Manufacturer Part Number: FLQ025
Series: FLQ Series
Fuse Type: Time-Delay Midget Fuse
Current Rating: 25A
Voltage Rating: 500V AC
AC / DC: AC
Breaking Capacity: 10kA
Package / Dimensions: 10×38mm
Mounting: Cartridge / Clip
Application: Control circuits · Motor · Transformer
Standard: UL 248-14
Terminal Type: Ferrule
Fuse Speed: Time Delay
Utilization Class: Supplemental
Approvals: CE · CSA · RoHS · UL Listed
Certifications: UL Listed · CSA · CE · RoHS
DC Voltage Rating: 300V DC
DC Interrupting Rating: 10kA (Littelfuse self-certified)
