HOLLY FUSE NH3LaRB500U15 1500V DC 500A aR Fuse

Hollyland

HOLLY FUSE NH3LaRB500U15 1500V DC 500A aR Fuse

Part Number: NH3LaRB500U15

● Check availability

Manufacturer-verified specifications for HOLLY FUSE NH3LaRB500U15: 500A, 1500V DC. Interrupting capacity: 250,000A at 1500V DC. Confirmed approvals: cURus.

Rated Current500A

Rated Voltage1500V DC

Breaking Capacity250,000A at 1500V DC

Tags

1500V DC aR Bolt-Down Semiconductor Fuses Very Fast Acting

HOLLY FUSE NH3LaRB500U15: aR semiconductor fuse, 500A, 1500V DC. The catalog specifies 250,000a at 1500v dc. Confirmed approvals: cURus. Standards: UL 248-13, IEC 60269-4, GB/T 13539.4. Manufacturer source: Powerfuse catalog page 80.

Technical Specifications

Part Number: NH3LaRB500U15
Manufacturer Part Number: NH3LaRB500U15
Series: NH3LaR-B
Fuse Type: Semiconductor Fuses
Current Rating: 500A
Voltage Rating: 1500V DC
AC / DC: DC
Breaking Capacity: 250,000A at 1500V DC
Mounting: Bolt-Down
Application: Power Electronics
Standard: GB/T 13539.4 · IEC 60269-4 · UL 248-13
Terminal Type: Ferrule
Fuse Speed: Very Fast Acting
Utilization Class: aR
Approvals: cURus
Certifications: cURus
Reference Lead Time: 2–4 weeks
Rated current: 500A
Rated voltage: 1500V DC
Interrupting capacity: 250,000A at 1500V DC
Class of operation: aR
Confirmed approvals: cURus
Standards: UL 248-13, IEC 60269-4, GB/T 13539.4
Source: Hollyland Powerfuse catalog, page 80
