HOLLY FUSE NH3LaBat800U15 1500V DC 800A Battery Fuse

Hollyland

HOLLY FUSE NH3LaBat800U15 1500V DC 800A Battery Fuse

Part Number: NH3LaBat800U15

● Check availability

HOLLY FUSE NH3LaBat800U15 combines a 800A current rating with 1500V DC operation for demanding protection applications. Confirmed approvals: cURus.

Rated Current800A

Rated Voltage1500V DC

Breaking Capacity250,000A at 1500V DC

Tags

1500V DC aR Bolt-Down Semiconductor Fuses Very Fast Acting

Part NH3LaBat800U15 is a HOLLY FUSE NH3LaBat-series battery protection fuse with ratings of 800A, 1500V DC. Confirmed approvals: cURus. Interrupting capacity: 250,000A at 1500V DC. Standards: UL 248-13, IEC 60269-7. Technical data checked against catalog page 81.

Technical Specifications

Part Number: NH3LaBat800U15
Manufacturer Part Number: NH3LaBat800U15
Series: NH3LaBat
Fuse Type: Semiconductor Fuses
Current Rating: 800A
Voltage Rating: 1500V DC
AC / DC: DC
Breaking Capacity: 250,000A at 1500V DC
Mounting: Bolt-Down
Application: Battery energy storage systems
Standard: IEC 60269-7 · UL 248-13
Terminal Type: Ferrule
Fuse Speed: Very Fast Acting
Approvals: cURus
Certifications: cURus
Reference Lead Time: 2–4 weeks
Rated current: 800A
Rated voltage: 1500V DC
Interrupting capacity: 250,000A at 1500V DC
Confirmed approvals: cURus
Standards: UL 248-13, IEC 60269-7
Source: Hollyland Powerfuse catalog, page 81
