What are the current and voltage ratings of NH01LgG50U11B?

NH01LgG50U11B is rated 50A at 1140V AC.

What is the breaking capacity of NH01LgG50U11B?

NH01LgG50U11B has a breaking capacity of 100,000A at 1140V AC. Confirm this covers the available fault current at the installation point.

What package size does NH01LgG50U11B use?

NH01LgG50U11B uses NH01 package size.

Which standards and approvals apply to NH01LgG50U11B?

NH01LgG50U11B is listed under GB/T 13539.1, IEC 60269-1.

What is NH01LgG50U11B used for?

NH01LgG50U11B is listed for Industrial Circuit Protection applications. Verify suitability for your circuit before ordering.

Hollyland

HOLLY FUSE NH01LgG50U11B 1140V AC 50A gG Fuse

Name: HOLLY FUSE NH01LgG50U11B 1140V AC 50A gG Fuse
Brand: Hollyland
SKU: NH01LgG50U11B

Part Number: NH01LgG50U11B

● Check availability

Manufacturer-checked NH01LgG50U11B: 50A, 1140V AC, general-purpose / time-lag nh fuse for industrial circuit protection.

Rated Current50A

Rated Voltage1140V AC

Breaking Capacity100,000A at 1140V AC

PackageNH01

Tags

1140V AC General-Purpose / Time-Lag gG NH Fuse NH01 NH01LgG

The HOLLY FUSE NH01LgG50U11B is intended for industrial circuit protection. Key ratings are 50A and 1140V AC, with a general-purpose / time-lag characteristic. Manufacturer reference: Powerfuse p95.

Specifications

Series: NH01LgG
Rated current: 50A
Rated voltage: 1140V AC
Fuse characteristic: General-Purpose / Time-Lag
Standards: IEC 60269.1, GB/T 13539.1
Interrupting capacity: 100,000A at 1140V AC
Confirmed approvals: none shown as approved for this exact row
pending marks excluded
Source: Hollyland Powerfuse p95

Technical Specifications

Part Number: NH01LgG50U11B
Manufacturer Part Number: NH01LgG50U11B
Series: NH01LgG
Fuse Type: NH Fuse
Current Rating: 50A
Voltage Rating: 1140V AC
AC / DC: AC
Breaking Capacity: 100,000A at 1140V AC
Package / Dimensions: NH01
Mounting: Blade / Fuse Base
Application: Industrial Circuit Protection
Standard: GB/T 13539.1 · IEC 60269-1
Terminal Type: Blade
Fuse Speed: Time Delay
Utilization Class: gG
Rated current: 50A
Rated voltage: 1140V AC
Fuse characteristic: General-Purpose / Time-Lag
Standards: IEC 60269.1, GB/T 13539.1
Interrupting capacity: 100,000A at 1140V AC
Confirmed approvals: none shown as approved for this exact row; pending marks excluded
Source: Hollyland Powerfuse p95
