Hollyland

HOLLY FUSE HB7EV400 750V 400A EV Fuse

Name: HOLLY FUSE HB7EV400 750V 400A EV Fuse
Brand: Hollyland
SKU: HB7EV400

Part Number: HB7EV400

● Check availability

HB7EV400 is part of the HOLLY FUSE HB7EV range, specified at 400A, 750V.

Rated Current400A

Rated Voltage750V

Breaking Capacity50000A at 750V DC

Tags

Bolt-Down EV Fuses gR Very Fast Acting

The HOLLY FUSE HB7EV400 ev fuse carries 400A, 750V and belongs to the HB7EV family. Standards: ISO 8820. Approvals: RoHS. Interrupting/breaking capacity: 50000A at 750V DC.

Specifications

Type: EV Fuse
Rated current type: DC
Standards also cited: GB/T 31465.6, ISO 8820-6, ISO 8820-8
Source: powerfuse catalogue page 15

Technical Specifications

Part Number: HB7EV400
Manufacturer Part Number: HB7EV400
Series: HB7EV
Fuse Type: EV Fuses
Current Rating: 400A
Voltage Rating: 750V
AC / DC: DC
Breaking Capacity: 50000A at 750V DC
Mounting: Bolt-Down
Application: EV
Standard: ISO 8820
Terminal Type: Ferrule
Fuse Speed: Very Fast Acting
Utilization Class: gR
Approvals: RoHS
Certifications: RoHS
Type: EV Fuse; Rated current type: DC; Standards also cited: GB/T 31465.6, ISO 8820-6, ISO 8820-8; Source: powerfuse catalogue page 15
