HOLLY FUSE H3BHG315U20XE 2000V 315A Photovoltaic Fuse

Name: HOLLY FUSE H3BHG315U20XE 2000V 315A Photovoltaic Fuse
Brand: Hollyland
SKU: H3BHG315U20XE

Part Number: H3BHG315U20XE

● LT: 2-4w

Product data for HOLLY FUSE H3BHG315U20XE photovoltaic fuse: 315A, 2000V; approvals include RoHS.

Rated Current315A

Rated Voltage2000V

Breaking Capacity50000A at 2000V DC

PackageNH3

Tags

Bolt-Down gPV NH3 Photovoltaic Fuses Very Fast Acting

HOLLY FUSE part H3BHG315U20XE is listed as a photovoltaic fuse with 315A, 2000V under the H3BHG series. Standards: IEC 60269. Approvals: RoHS. Interrupting/breaking capacity: 50000A at 2000V DC.

Specifications

Rating table: 50,000 amperes at 2000V DC | Type: H3BHG Part No.: H3BHGXXXU20X
Type: Photovoltaic Fuses
Rated current type: DC
Standards also cited: IEC 60269-6
Source: powerfuse catalogue page 47

Technical Specifications

Part Number: H3BHG315U20XE
Manufacturer Part Number: H3BHG315U20XE
Series: H3BHG
Fuse Type: Photovoltaic Fuses
Current Rating: 315A
Voltage Rating: 2000V
AC / DC: DC
Breaking Capacity: 50000A at 2000V DC
Package / Dimensions: NH3
Mounting: Bolt-Down
Application: Solar PV
Standard: IEC 60269
Terminal Type: Ferrule
Fuse Speed: Very Fast Acting
Utilization Class: gPV
Approvals: RoHS
Certifications: RoHS
Rating table: 50,000 amperes at 2000V DC | Type: H3BHG Part No.: H3BHGXXXU20X
Type: Photovoltaic Fuses
Rated current type: DC
Standards also cited: IEC 60269-6
Source: powerfuse catalogue page 47
