What are the current and voltage ratings of H1BF450C?

H1BF450C is rated 450A at 1250V AC / 1000V DC.

What is the breaking capacity of H1BF450C?

H1BF450C has a breaking capacity of 100,000A at 1250V AC / 50,000A at 1000V DC. Confirm this covers the available fault current at the installation point.

What package size does H1BF450C use?

H1BF450C uses NH1 package size.

Which standards and approvals apply to H1BF450C?

H1BF450C is listed under GB/T 13539.4, IEC 60269-4, UL 248-13 / TUV · CE · CCC · cURus.

What is H1BF450C used for?

H1BF450C is listed for Power Electronics applications. Verify suitability for your circuit before ordering.

What are the ordering terms for H1BF450C?

H1BF450C: typical lead time 2–4 weeks. Submit a quote request for a firm quotation.

Hollyland

HOLLY FUSE H1BF450C 1250V AC / 1000V DC 450A aR Fuse

Name: HOLLY FUSE H1BF450C 1250V AC / 1000V DC 450A aR Fuse
Brand: Hollyland
SKU: H1BF450C

Part Number: H1BF450C

● Check availability

HOLLY FUSE H1BF450C combines a 450A current rating with 1250V AC / 1000V DC operation for demanding protection applications. Confirmed approvals: TUV, CE, CCC, cURus.

Rated Current450A

Rated Voltage1250V AC / 1000V DC

Breaking Capacity100,000A at 1250V AC / 50,000A at 1000V DC

PackageNH1

Tags

aR Bolt-Down fuse NH1 Very Fast Acting

Part H1BF450C is a HOLLY FUSE H1BF-series aR semiconductor fuse with ratings of 450A, 1250V AC / 1000V DC. Confirmed approvals: TUV, CE, CCC, cURus. Interrupting capacity: 100,000A at 1250V AC / 50,000A at 1000V DC. Standards: IEC 60269-4, GB/T 13539.4, UL 248-13. Technical data checked against catalog page 61.
