What are the current and voltage ratings of H1BF400?

H1BF400 is rated 400A at 1250V AC / 1000V DC.

What is the breaking capacity of H1BF400?

H1BF400 has a breaking capacity of 100,000A at 1250V AC / 50,000A at 1000V DC. Confirm this covers the available fault current at the installation point.

Which standards and approvals apply to H1BF400?

H1BF400 is listed under GB/T 13539.4, IEC 60269-4, UL 248-13 / TUV · CE · CCC · cURus.

What is H1BF400 used for?

H1BF400 is listed for Power Electronics applications. Verify suitability for your circuit before ordering.

What are the ordering terms for H1BF400?

H1BF400: typical lead time 2–4 weeks. Submit a quote request for a firm quotation.

Hollyland

HOLLY FUSE H1BF400 1250V AC / 1000V DC 400A aR Fuse

Name: HOLLY FUSE H1BF400 1250V AC / 1000V DC 400A aR Fuse
Brand: Hollyland
SKU: H1BF400

Part Number: H1BF400

● Check availability

H1BF400 is part of the HOLLY FUSE H1BF family, specified at 400A, 1250V AC / 1000V DC for electrical protection systems. Confirmed approvals: TUV, CE, CCC, cURus.

Rated Current400A

Rated Voltage1250V AC / 1000V DC

Breaking Capacity100,000A at 1250V AC / 50,000A at 1000V DC

PackageNH1

Tags

aR Bolt-Down fuse NH1 Very Fast Acting

Designed for power-electronics protection, HOLLY FUSE H1BF400 is specified at 400A, 1250V AC / 1000V DC within the H1BF series. Interrupting capacity: 100,000A at 1250V AC / 50,000A at 1000V DC. Confirmed approvals: TUV, CE, CCC, cURus. Standards: IEC 60269-4, GB/T 13539.4, UL 248-13. Source: manufacturer catalog page 61.
