What are the current and voltage ratings of H0BD550?

H0BD550 is rated 550A at 690V AC / 500V DC.

What is the breaking capacity of H0BD550?

H0BD550 has a breaking capacity of 200,000A at 690V AC / 50,000A at 500V DC. Confirm this covers the available fault current at the installation point.

Which standards and approvals apply to H0BD550?

H0BD550 is listed under GB/T 13539.4, IEC 60269-4, UL 248-13 / cURus.

What is H0BD550 used for?

H0BD550 is listed for Power Electronics applications. Verify suitability for your circuit before ordering.

What are the ordering terms for H0BD550?

H0BD550: typical lead time 2–4 weeks. Submit a quote request for a firm quotation.

Hollyland

HOLLY FUSE H0BD550 690V AC / 500V DC 550A aR Fuse

Name: HOLLY FUSE H0BD550 690V AC / 500V DC 550A aR Fuse
Brand: Hollyland
SKU: H0BD550

Part Number: H0BD550

● Check availability

HOLLY FUSE H0BD550 combines a 550A current rating with 690V AC / 500V DC operation for demanding protection applications. Confirmed approvals: cURus.

Rated Current550A

Rated Voltage690V AC / 500V DC

Breaking Capacity200,000A at 690V AC / 50,000A at 500V DC

PackageNH0

Tags

Part H0BD550 is a HOLLY FUSE H0BD-series aR semiconductor fuse with ratings of 550A, 690V AC / 500V DC. Confirmed approvals: cURus. Interrupting capacity: 200,000A at 690V AC / 50,000A at 500V DC. Standards: IEC 60269-4, GB/T 13539.4, UL 248-13. Technical data checked against catalog page 59.
