What are the current and voltage ratings of H0BD500C?

H0BD500C is rated 500A at 690V AC / 500V DC.

What is the breaking capacity of H0BD500C?

H0BD500C has a breaking capacity of 200,000A at 690V AC / 50,000A at 500V DC. Confirm this covers the available fault current at the installation point.

What package size does H0BD500C use?

H0BD500C uses NH0 package size.

Which standards and approvals apply to H0BD500C?

H0BD500C is listed under GB/T 13539.4, IEC 60269-4, UL 248-13 / cURus.

What is H0BD500C used for?

H0BD500C is listed for Power Electronics applications. Verify suitability for your circuit before ordering.

What are the ordering terms for H0BD500C?

H0BD500C: typical lead time 2–4 weeks. Submit a quote request for a firm quotation.

Hollyland

HOLLY FUSE H0BD500C 690V AC / 500V DC 500A aR Fuse

Name: HOLLY FUSE H0BD500C 690V AC / 500V DC 500A aR Fuse
Brand: Hollyland
SKU: H0BD500C

Part Number: H0BD500C

● Check availability

Manufacturer-verified specifications for HOLLY FUSE H0BD500C: 500A, 690V AC / 500V DC. Interrupting capacity: 200,000A at 690V AC / 50,000A at 500V DC. Confirmed approvals: cURus.

Rated Current500A

Rated Voltage690V AC / 500V DC

Breaking Capacity200,000A at 690V AC / 50,000A at 500V DC

PackageNH0

Tags

HOLLY FUSE H0BD500C: aR semiconductor fuse, 500A, 690V AC / 500V DC. The catalog specifies 200,000a at 690v ac / 50,000a at 500v dc. Confirmed approvals: cURus. Standards: IEC 60269-4, GB/T 13539.4, UL 248-13. Manufacturer source: Powerfuse catalog page 59.
