HOLLY FUSE 65TS-016H 250V AC 1.6A Slow-Blow Ceramic Fuse

Name: HOLLY FUSE 65TS-016H 250V AC 1.6A Slow-Blow Ceramic Fuse
Brand: Hollyland
SKU: 65TS-016H

Part Number: 65TS-016H

● Check availability

HOLLY FUSE 65TS-016H combines its rated protection value with 250V AC operation in the 65TS product family.

Rated Current1.6A

Rated Voltage250V AC

Breaking Capacity100A at 250V AC

Package6.35×32mm

Tags

250V AC 6.35×32mm 65TS Ceramic Tube Fuse Slow-Blow

Part 65TS-016H is a HOLLY FUSE 65TS-series slow-blow ceramic fuse with specifications of 1.6A, 250V AC. Interrupting capacity: 100A at 250V AC. Standards: UL 248-1, UL 248-14. Technical data checked against catalogue p46.

Technical Specifications

Part Number: 65TS-016H
Manufacturer Part Number: 65TS-016H
Series: 65TS
Fuse Type: Ceramic Tube Fuse
Current Rating: 1.6A
Voltage Rating: 250V AC
AC / DC: AC
Breaking Capacity: 100A at 250V AC
I²t: 1.521 A²s
Operating Temperature: -55°C to +125°C
Package / Dimensions: 6.35×32mm
Mounting: Cartridge / Clip
Application: Electronic Circuit Protection
Standard: UL 248-1 · UL 248-14
Terminal Type: Ferrule
Fuse Speed: Time Delay
Reference Lead Time: 2–4 weeks
Rated current: 1.6A
Rated voltage: 250V AC
Fuse characteristic: Slow-Blow
Fuse construction: Ceramic Tube Fuse
Interrupting capacity: 100A at 250V AC
Standards: UL 248-1, UL 248-14
Manufacturer approval note: UL/cUL, UR/cUR, PSE, KC, TÜV and CQC are listed; exact approvals vary by suffix/current.
Source: Hollyland Current Fuse catalogue, printed page 46
