HOLLY FUSE 51S-0150H 250V AC 150mA Slow-Blow Glass Fuse

Name: HOLLY FUSE 51S-0150H 250V AC 150mA Slow-Blow Glass Fuse
Brand: Hollyland
SKU: 51S-0150H

Part Number: 51S-0150H

● Check availability

51S-0150H from HOLLY FUSE provides 150mA, 250V AC circuit protection in the 51S series. Confirmed common approvals: UL, cUL.

Rated Current150mA

Rated Voltage250V AC

Breaking Capacity35A at 250V AC

Package5.2×20mm

Tags

250V AC 5×20mm Cartridge / Clip Glass Tube Fuses Time-Lag (T)

For applications requiring 150mA, 250V AC, HOLLY FUSE 51S-0150H provides the manufacturer-specified characteristics of the 51S family. Interrupting capacity: 35A at 250V AC. Standards: UL 248-1, UL 248-14. Confirmed common approvals: UL, cUL. Verified against catalogue p34.

Technical Specifications

Part Number: 51S-0150H
Manufacturer Part Number: 51S-0150H
Series: 51S
Fuse Type: Glass Tube Fuse
Current Rating: 150mA
Voltage Rating: 250V AC
AC / DC: AC
Breaking Capacity: 35A at 250V AC
Operating Temperature: -55°C to +125°C
Package / Dimensions: 5.2×20mm
Mounting: Cartridge / Clip
Application: Electronic Circuit Protection
Standard: UL 248-1 · UL 248-14
Terminal Type: Ferrule
Fuse Speed: Time Delay
Approvals: cULus · UL
Certifications: UL · cUL
Reference Lead Time: 2–4 weeks
Rated current: 150mA
Rated voltage: 250V AC
Fuse characteristic: Slow-Blow
Fuse construction: Glass Tube Fuse
Standards: UL 248-1, UL 248-14
Interrupting capacity: 35A at 250V AC
Manufacturer-listed approval authorities: UL/cUL, UR, CSA, PSE and KC are listed by the manufacturer; exact approvals vary by rating/voltage.
Operating temperature: -55°C to +125°C
Source: Hollyland Current Fuse catalogue, printed page 34
