Hollyland

HOLLY FUSE 31S-016L 125V AC 1.6A Slow-Blow Glass Microfuse

Name: HOLLY FUSE 31S-016L 125V AC 1.6A Slow-Blow Glass Microfuse
Brand: Hollyland
SKU: 31S-016L

Part Number: 31S-016L

● Check availability

Technical listing for 31S-016L: 1.6A, 125V AC slow-blow glass microfuse with manufacturer-verified operating characteristics. Confirmed common approvals: UL, cUL.

Rated Current1.6A

Rated Voltage125V AC

Breaking Capacity50A at 125V AC

Package3.6×10mm

Tags

125V AC 3.6×10mm Cartridge / Clip Glass Tube Fuses Time-Lag (T)

The 31S-016L fuse is listed by HOLLY FUSE for 1.6A, 125V AC. It belongs to the 31S family and uses a slow-blow characteristic. Interrupting capacity: 50A at 125V AC. Confirmed common approvals: UL, cUL. Manufacturer source: Current Fuse catalogue p27.

Technical Specifications

Part Number: 31S-016L
Manufacturer Part Number: 31S-016L
Series: 31S
Fuse Type: Glass Tube Microfuse
Current Rating: 1.6A
Voltage Rating: 125V AC
AC / DC: AC
Breaking Capacity: 50A at 125V AC
Operating Temperature: -55°C to +125°C
Package / Dimensions: 3.6×10mm
Mounting: Cartridge / Clip
Application: Electronic Circuit Protection
Standard: UL 248-1 · UL 248-14
Terminal Type: Ferrule
Fuse Speed: Time Delay
Approvals: cULus · UL
Certifications: UL · cUL
Reference Lead Time: 2–4 weeks
Rated current: 1.6A
Rated voltage: 125V AC
Fuse characteristic: Slow-Blow
Fuse construction: Glass Tube Microfuse
Standards: UL 248-1, UL 248-14
Interrupting capacity: 50A at 125V AC
Manufacturer-listed approval authorities: UL/cUL and CSA are listed by the manufacturer; exact approvals vary by rating/voltage.
Operating temperature: -55°C to +125°C
Source: Hollyland Current Fuse catalogue, printed page 27
