Hollyland

HOLLY FUSE 30N-0750H1 350V AC 750mA Microfuse

Name: HOLLY FUSE 30N-0750H1 350V AC 750mA Microfuse
Brand: Hollyland
SKU: 30N-0750H1

Part Number: 30N-0750H1

● Check availability

HOLLY FUSE 30N-0750H1 is a Microfuse rated 750mA at 350V AC, with catalog-checked technical data.

Rated Current750mA

Rated Voltage350V AC

Breaking Capacity50A at 125V/250V/350V AC; PSE up to 100A

Package3.6×10mm

Tags

3.6×10mm 30N 350V AC fast acting Microfuse

HOLLY FUSE 30N-0750H1 belongs to the 30N series and is specified as a microfuse rated 750mA at 350V AC. Interrupting capacity: 50A at 125V/250V/350V AC; PSE up to 100A. Standards: UL 248-1, UL 248-14. Source: Hollyland Current Fuse p24.

Technical Specifications

Part Number: 30N-0750H1
Manufacturer Part Number: 30N-0750H1
Series: 30N
Fuse Type: Microfuse
Current Rating: 750mA
Voltage Rating: 350V AC
AC / DC: AC
Breaking Capacity: 50A at 125V/250V/350V AC; PSE up to 100A
I²t: 0.1978 A²s
Pre-arcing I²t: 0.1978
Total I²t: 0.1978
Operating Temperature: -55°C to +125°C
Package / Dimensions: 3.6×10mm
Mounting: Cartridge / Leaded
Application: Electronic Circuit Protection
Standard: UL 248-1 · UL 248-14
Terminal Type: Radial Lead
Fuse Speed: Fast Acting
Rated current: 750mA
Rated voltage: 350V AC
Fuse characteristic: Fast Acting
Standards: UL 248-1, UL 248-14
Interrupting capacity: 50A at 125V/250V/350V AC; PSE up to 100A
Manufacturer-listed approval authorities: UL/cUL, CSA, PSE. Availability varies by rating/voltage; verify the exact catalog row.
Operating temperature: -55°C to +125°C
Source: Hollyland Current Fuse p24
