Hollyland

HOLLY FUSE 20S-016L 125V AC 1.6A Microfuse

Name: HOLLY FUSE 20S-016L 125V AC 1.6A Microfuse
Brand: Hollyland
SKU: 20S-016L

Part Number: 20S-016L

● Check availability

HOLLY FUSE 20S-016L is a Microfuse rated 1.6A at 125V AC, with catalog-checked technical data.

Rated Current1.6A

Rated Voltage125V AC

Breaking Capacity50A at 125V/250V AC; PSE up to 100A

Package2.4×7mm

Tags

125V AC 2.4×7mm 20S Medium Slow-Blow Microfuse

HOLLY FUSE 20S-016L belongs to the 20S series and is specified as a microfuse rated 1.6A at 125V AC. Interrupting capacity: 50A at 125V/250V AC; PSE up to 100A. Standards: UL 248-1, UL 248-14. Source: Hollyland Current Fuse p21.

Technical Specifications

Part Number: 20S-016L
Manufacturer Part Number: 20S-016L
Series: 20S
Fuse Type: Microfuse
Current Rating: 1.6A
Voltage Rating: 125V AC
AC / DC: AC
Breaking Capacity: 50A at 125V/250V AC; PSE up to 100A
I²t: 2.374 A²s
Pre-arcing I²t: 2.374
Total I²t: 2.374
Operating Temperature: -55°C to +125°C
Package / Dimensions: 2.4×7mm
Mounting: Cartridge / Leaded
Application: Electronic Circuit Protection
Standard: UL 248-1 · UL 248-14
Terminal Type: Radial Lead
Fuse Speed: Medium Time-Delay
Rated current: 1.6A
Rated voltage: 125V AC
Fuse characteristic: Medium Slow-Blow
Standards: UL 248-1, UL 248-14
Interrupting capacity: 50A at 125V/250V AC; PSE up to 100A
Manufacturer-listed approval authorities: CCC, UL/cUL, CSA, PSE. Availability varies by rating/voltage; verify the exact catalog row.
Operating temperature: -55°C to +125°C
Source: Hollyland Current Fuse p21
