HOLLY FUSE 20N-025L 125V AC/DC 2.5A Microfuse

Name: HOLLY FUSE 20N-025L 125V AC/DC 2.5A Microfuse
Brand: Hollyland
SKU: 20N-025L

Part Number: 20N-025L

● Check availability

HOLLY FUSE 20N-025L is a Microfuse rated 2.5A at 125V AC/DC, with catalog-checked technical data.

Rated Current2.5A

Rated Voltage125V AC/DC

Breaking Capacity30–50A by voltage/current; PSE up to 100A

Package2.4×7mm

Tags

125V AC/DC 2.4×7mm 20N Microfuse Very Quick-Acting

HOLLY FUSE 20N-025L belongs to the 20N series and is specified as a microfuse rated 2.5A at 125V AC/DC. Interrupting capacity: 30–50A by voltage/current; PSE up to 100A. Standards: UL 248-1, UL 248-14. Source: Hollyland Current Fuse p20.

Technical Specifications

Part Number: 20N-025L
Manufacturer Part Number: 20N-025L
Series: 20N
Fuse Type: Microfuse
Current Rating: 2.5A
Voltage Rating: 125V AC/DC
AC / DC: AC/DC
Breaking Capacity: 30–50A by voltage/current; PSE up to 100A
I²t: 1.899 A²s
Pre-arcing I²t: 1.899
Total I²t: 1.899
Operating Temperature: -55°C to +125°C
Package / Dimensions: 2.4×7mm
Mounting: Cartridge / Leaded
Application: Electronic Circuit Protection
Standard: UL 248-1 · UL 248-14
Terminal Type: Radial Lead
Fuse Speed: Very Fast Acting
Rated current: 2.5A
Rated voltage: 125V AC/DC
Fuse characteristic: Very Quick-Acting
Standards: UL 248-1, UL 248-14
Interrupting capacity: 30–50A by voltage/current; PSE up to 100A
Manufacturer-listed approval authorities: CCC, UL/cUL, UR/cUR, CSA, PSE. Availability varies by rating/voltage; verify the exact catalog row.
Operating temperature: -55°C to +125°C
Source: Hollyland Current Fuse p20
