HOLLY FUSE 14LgPV6U15 1500V 6A Photovoltaic Fuse

Name: HOLLY FUSE 14LgPV6U15 1500V 6A Photovoltaic Fuse
Brand: Hollyland
SKU: 14LgPV6U15

Part Number: 14LgPV6U15

● LT: 2-4w

Technical listing for HOLLY FUSE 14LgPV6U15, a photovoltaic fuse with 6A, 1500V and UL Listed approval.

Rated Current6A

Rated Voltage1500V

Breaking Capacity30000A at 1500V DC

Package14×51mm

Tags

14x51mm 1500V DC Bolt-Down gPV Photovoltaic Fuses Very Fast Acting

HOLLY FUSE part 14LgPV6U15 is listed as a photovoltaic fuse with 6A, 1500V under the HC14LgPV series. Standards: UL 248. Approvals: UL Listed. Interrupting/breaking capacity: 30000A at 1500V DC.

Specifications

Type: Photovoltaic Fuses
Rated current type: DC
Standards also cited: UL 248-19
Source: powerfuse catalogue page 36

Technical Specifications

Part Number: 14LgPV6U15
Manufacturer Part Number: 14LgPV6U15
Series: HC14LgPV
Fuse Type: Photovoltaic Fuses
Current Rating: 6A
Voltage Rating: 1500V
AC / DC: DC
Breaking Capacity: 30000A at 1500V DC
Package / Dimensions: 14×51mm
Mounting: Bolt-Down
Application: Solar PV
Standard: UL 248
Terminal Type: Ferrule
Fuse Speed: Very Fast Acting
Utilization Class: gPV
Approvals: UL Listed
Certifications: UL Listed
Type: Photovoltaic Fuses; Rated current type: DC; Standards also cited: UL 248-19; Source: powerfuse catalogue page 36
