Hollyland

HOLLY FUSE 140EV10T 1000V 10A EV Fuse

Name: HOLLY FUSE 140EV10T 1000V 10A EV Fuse
Brand: Hollyland
SKU: 140EV10T

Part Number: 140EV10T

● Check availability

HOLLY FUSE 140EV10T is a ev fuse rated 10A, 1000V in the HC140EV-T series.

Rated Current10A

Rated Voltage1000V

Breaking Capacity20000A at 1000V DC

Package14×51mm

Tags

1000V DC 14x51mm Bolt-Down EV Fuses gR Very Fast Acting

HOLLY FUSE 140EV10T is a ev fuse in the HC140EV-T series, rated 10A, 1000V. Standards: ISO 8820. Approvals: RoHS. Interrupting/breaking capacity: 20000A at 1000V DC.

Specifications

Type: EV Fuse
Rated current type: DC
Standards also cited: GB/T 31465.6, ISO 8820-6
Source: powerfuse catalogue page 13

Technical Specifications

Part Number: 140EV10T
Manufacturer Part Number: 140EV10T
Series: HC140EV-T
Fuse Type: EV Fuses
Current Rating: 10A
Voltage Rating: 1000V
AC / DC: DC
Breaking Capacity: 20000A at 1000V DC
Package / Dimensions: 14×51mm
Mounting: Bolt-Down
Application: EV
Standard: ISO 8820
Terminal Type: Ferrule
Fuse Speed: Very Fast Acting
Utilization Class: gR
Approvals: RoHS
Certifications: RoHS
Type: EV Fuse; Rated current type: DC; Standards also cited: GB/T 31465.6, ISO 8820-6; Source: powerfuse catalogue page 13
