HOLLY FUSE 12T-0800L 24V / 32V / 63V 800mA Surface Mount Fuse

Name: HOLLY FUSE 12T-0800L 24V / 32V / 63V 800mA Surface Mount Fuse
Brand: Hollyland
SKU: 12T-0800L

Part Number: 12T-0800L

● Check availability

12T-0800L is a HOLLY FUSE surface mount fuse with verified ratings of 800mA and 24V / 32V / 63V.

Rated Current800mA

Rated Voltage24V / 32V / 63V

Breaking CapacityUp to 50A; varies by current and voltage

Package1206

Tags

Technical data for HOLLY FUSE 12T-0800L includes 800mA, 24V / 32V / 63V, slow-blow / time-lag operation and UL 248-1, UL 248-14 standards.

Series: 12T
Rated current: 800mA
Rated voltage: 24V / 32V / 63V
Fuse characteristic: Slow-Blow / Time-Lag
Standards: UL 248-1, UL 248-14
Interrupting capacity: Up to 50A
varies by current and voltage
Manufacturer-listed approval authorities: UR, cUR. Availability varies by rating/voltage
verify the exact catalog row.
Operating temperature: -55°C to +125°C
Source: Hollyland Current Fuse p10

Technical Specifications

Part Number: 12T-0800L
Manufacturer Part Number: 12T-0800L
Series: 12T
Fuse Type: Surface Mount Fuse
Current Rating: 800mA
Voltage Rating: 24V / 32V / 63V
AC / DC: AC/DC
Breaking Capacity: Up to 50A; varies by current and voltage
I²t: 0.0699 A²s
Pre-arcing I²t: 0.0699
Total I²t: 0.0699
Operating Temperature: -55°C to +125°C
Package / Dimensions: 1206
Mounting: SMD
Application: PCB / Electronic Circuit Protection
Standard: UL 248-1 · UL 248-14
Terminal Type: SMD End Pad
Fuse Speed: Time Delay
Rated current: 800mA
Rated voltage: 24V / 32V / 63V
Fuse characteristic: Slow-Blow / Time-Lag
Standards: UL 248-1, UL 248-14
Interrupting capacity: Up to 50A; varies by current and voltage
Manufacturer-listed approval authorities: UR, cUR. Availability varies by rating/voltage; verify the exact catalog row.
Operating temperature: -55°C to +125°C
Source: Hollyland Current Fuse p10
