HOLLY FUSE 10PV20U0 1000V 20A Photovoltaic Fuse

Name: HOLLY FUSE 10PV20U0 1000V 20A Photovoltaic Fuse
Brand: Hollyland
SKU: 10PV20U0

Part Number: 10PV20U0

● Check availability

10PV20U0 photovoltaic fuse from HOLLY FUSE combines a 20A current rating with a 1000V voltage rating.

Rated Current20A

Rated Voltage1000V

Breaking Capacity30000A at 1000V DC

Package10×38mm

Tags

10×38mm 1000V DC Bolt-Down gPV Photovoltaic Fuses Very Fast Acting

The HOLLY FUSE 10PV20U0 photovoltaic fuse carries 20A, 1000V and belongs to the HC10PV family. Standards: UL 248. Approvals: UL Listed. Interrupting/breaking capacity: 30000A at 1000V DC.

Specifications

Type: Photovoltaic Fuses
Rated current type: DC
Standards also cited: UL 248-19
Source: powerfuse catalogue page 28

Technical Specifications

Part Number: 10PV20U0
Manufacturer Part Number: 10PV20U0
Series: HC10PV
Fuse Type: Photovoltaic Fuses
Current Rating: 20A
Voltage Rating: 1000V
AC / DC: DC
Breaking Capacity: 30000A at 1000V DC
Package / Dimensions: 10×38mm
Mounting: Bolt-Down
Application: Solar PV
Standard: UL 248
Terminal Type: Ferrule
Fuse Speed: Very Fast Acting
Utilization Class: gPV
Approvals: UL Listed
Certifications: UL Listed
Type: Photovoltaic Fuses; Rated current type: DC; Standards also cited: UL 248-19; Source: powerfuse catalogue page 28
