HOLLY FUSE 10NF-600 250V AC / 115V / 100V / 75V / 32V DC 60A SMD Nano Fuse

Name: HOLLY FUSE 10NF-600 250V AC / 115V / 100V / 75V / 32V DC 60A SMD Nano Fuse
Brand: Hollyland
SKU: 10NF-600

Part Number: 10NF-600

● Check availability

Use HOLLY FUSE 10NF-600 where a fast acting fuse rated 60A and 250V AC / 115V / 100V / 75V / 32V DC is required.

Rated Current60A

Rated Voltage250V AC / 115V / 100V / 75V / 32V DC

Breaking Capacity500A at 250V AC; up to 3,500A at lower DC voltages

PackageSMD Nano

Tags

10NF 250V AC / 115V / 100V / 75V / 32V DC fast acting SMD Nano SMD Nano Fuse

HOLLY FUSE specifies 10NF-600 at 60A and 250V AC / 115V / 100V / 75V / 32V DC. The device has a fast acting characteristic and catalog-grounded technical data from Current Fuse p16.

Specifications

Series: 10NF
Rated current: 60A
Rated voltage: 250V AC / 115V / 100V / 75V / 32V DC
Fuse characteristic: Fast Acting
Standards: UL 248-1, UL 248-14
Interrupting capacity: 500A at 250V AC
up to 3,500A at lower DC voltages
Manufacturer-listed approval authorities: cURus. Availability varies by rating/voltage
verify the exact catalog row.
Operating temperature: -55°C to +100°C
Source: Hollyland Current Fuse p16

Technical Specifications

Part Number: 10NF-600
Manufacturer Part Number: 10NF-600
Series: 10NF
Fuse Type: SMD Nano Fuse
Current Rating: 60A
Voltage Rating: 250V AC / 115V / 100V / 75V / 32V DC
AC / DC: AC/DC
Breaking Capacity: 500A at 250V AC; up to 3,500A at lower DC voltages
I²t: 1050 A²s
Pre-arcing I²t: 1050
Total I²t: 1050
Operating Temperature: -55°C to +100°C
Package / Dimensions: SMD Nano
Mounting: SMD
Application: PCB / Electronic Circuit Protection
Standard: UL 248-1 · UL 248-14
Terminal Type: SMD End Pad
Fuse Speed: Fast Acting
Rated current: 60A
Rated voltage: 250V AC / 115V / 100V / 75V / 32V DC
Fuse characteristic: Fast Acting
Standards: UL 248-1, UL 248-14
Interrupting capacity: 500A at 250V AC; up to 3,500A at lower DC voltages
Manufacturer-listed approval authorities: cURus. Availability varies by rating/voltage; verify the exact catalog row.
Operating temperature: -55°C to +100°C
Source: Hollyland Current Fuse p16
