Hollyland

HOLLY FUSE 10LgPV32U15 1500V 32A Photovoltaic Fuse

Name: HOLLY FUSE 10LgPV32U15 1500V 32A Photovoltaic Fuse
Brand: Hollyland
SKU: 10LgPV32U15

Part Number: 10LgPV32U15

● Check availability

Technical listing for HOLLY FUSE 10LgPV32U15, a photovoltaic fuse with 32A, 1500V and RoHS approval.

Rated Current32A

Rated Voltage1500V

Breaking Capacity30000A at 1500V DC

Package10×38mm

Tags

10×38mm 1500V DC Bolt-Down gPV Photovoltaic Fuses Very Fast Acting

HOLLY FUSE part 10LgPV32U15 is listed as a photovoltaic fuse with 32A, 1500V under the HC10LgPV series. Standards: IEC 60269. Approvals: RoHS. Interrupting/breaking capacity: 30000A at 1500V DC.

Specifications

Type: Photovoltaic Fuses
Rated current type: DC
Standards also cited: IEC 60269-6, GB/T 13539.6
Source: powerfuse catalogue page 31

Technical Specifications

Part Number: 10LgPV32U15
Manufacturer Part Number: 10LgPV32U15
Series: HC10LgPV
Fuse Type: Photovoltaic Fuses
Current Rating: 32A
Voltage Rating: 1500V
AC / DC: DC
Breaking Capacity: 30000A at 1500V DC
Package / Dimensions: 10×38mm
Mounting: Bolt-Down
Application: Solar PV
Standard: IEC 60269
Terminal Type: Ferrule
Fuse Speed: Very Fast Acting
Utilization Class: gPV
Approvals: RoHS
Certifications: RoHS
Type: Photovoltaic Fuses; Rated current type: DC; Standards also cited: IEC 60269-6, GB/T 13539.6; Source: powerfuse catalogue page 31
