What are the current and voltage ratings of 10aR1.6U0?

10aR1.6U0 is rated 1.6A at 1000V AC/DC.

What is the breaking capacity of 10aR1.6U0?

10aR1.6U0 has a breaking capacity of 50,000A at 1000V AC / 30,000A at 1000V DC. Confirm this covers the available fault current at the installation point.

What package size does 10aR1.6U0 use?

10aR1.6U0 uses 10×38mm package size.

Which standards and approvals apply to 10aR1.6U0?

10aR1.6U0 is listed under GB/T 13539.4, IEC 60269-4, UL 248-13 / CCC · VDE · cURus.

What is 10aR1.6U0 used for?

10aR1.6U0 is listed for Power Electronics applications. Verify suitability for your circuit before ordering.

What are the ordering terms for 10aR1.6U0?

10aR1.6U0: typical lead time 2–4 weeks. Submit a quote request for a firm quotation.

Hollyland

HOLLY FUSE 10aR1.6U0 1000V AC/DC 1.6A aR Fuse

Name: HOLLY FUSE 10aR1.6U0 1000V AC/DC 1.6A aR Fuse
Brand: Hollyland
SKU: 10aR1.6U0

Part Number: 10aR1.6U0

● Check availability

HOLLY FUSE 10aR1.6U0 combines a 1.6A current rating with 1000V AC/DC operation for demanding protection applications. Confirmed approvals: CCC, VDE, cURus.

Rated Current1.6A

Rated Voltage1000V AC/DC

Breaking Capacity50,000A at 1000V AC / 30,000A at 1000V DC

Package10×38mm

Tags

Part 10aR1.6U0 is a HOLLY FUSE HC10aR-series aR semiconductor fuse with ratings of 1.6A, 1000V AC/DC. Confirmed approvals: CCC, VDE, cURus. Interrupting capacity: 50,000A at 1000V AC / 30,000A at 1000V DC. Standards: IEC 60269-4, GB/T 13539.4, UL 248-13. Technical data checked against catalog page 85.
