What are the current and voltage ratings of 10aR-C15U0?

10aR-C15U0 is rated 15A at 1000V AC/DC.

What is the breaking capacity of 10aR-C15U0?

10aR-C15U0 has a breaking capacity of 50,000A at 1000V AC / 30,000A at 1000V DC. Confirm this covers the available fault current at the installation point.

What package size does 10aR-C15U0 use?

10aR-C15U0 uses 10.3×38mm package size.

Which standards and approvals apply to 10aR-C15U0?

10aR-C15U0 is listed under GB/T 13539.4, IEC 60269-4, UL 248-13.

What is 10aR-C15U0 used for?

10aR-C15U0 is listed for Power Electronics / Semiconductor Protection applications. Verify suitability for your circuit before ordering.

Hollyland

HOLLY FUSE 10aR-C15U0 1000V AC/DC 15A aR Semiconductor Fuse

Name: HOLLY FUSE 10aR-C15U0 1000V AC/DC 15A aR Semiconductor Fuse
Brand: Hollyland
SKU: 10aR-C15U0

Part Number: 10aR-C15U0

● Check availability

HOLLY FUSE HC10aR-C part 10aR-C15U0 combines a 15A current rating with 1000V AC/DC operation.

Rated Current15A

Rated Voltage1000V AC/DC

Breaking Capacity50,000A at 1000V AC / 30,000A at 1000V DC

Package10.3×38mm

Tags

Part 10aR-C15U0 is a HC10aR-C-series cylindrical semiconductor fuse for semiconductor / power electronics protection, rated 15A at 1000V AC/DC. Applicable standards: IEC 60269-4, GB/T 13539.4, UL 248-13.

Technical Specifications

Part Number: 10aR-C15U0
Manufacturer Part Number: 10aR-C15U0
Series: HC10aR-C
Fuse Type: Cylindrical Semiconductor Fuse
Current Rating: 15A
Voltage Rating: 1000V AC/DC
AC / DC: AC/DC
Breaking Capacity: 50,000A at 1000V AC / 30,000A at 1000V DC
Package / Dimensions: 10.3×38mm
Mounting: Cartridge / Clip
Application: Power Electronics / Semiconductor Protection
Standard: GB/T 13539.4 · IEC 60269-4 · UL 248-13
Terminal Type: Ferrule
Fuse Speed: Very Fast Acting
Utilization Class: aR
Rated current: 15A
Rated voltage: 1000V AC/DC
Fuse characteristic: Very Fast Acting
Standards: IEC 60269-4, GB/T 13539.4, UL 248-13
Interrupting capacity: 50,000A at 1000V AC / 30,000A at 1000V DC
Confirmed approvals: none shown as approved for this exact row; pending marks excluded
Source: Hollyland Powerfuse p86
