Dissmann

Dissmann MEV-P-C30-80 80A AC690V/DC750V aR Industrial Fuse

Name: Dissmann MEV-P-C30-80 80A AC690V/DC750V aR Industrial Fuse
Brand: Dissmann
SKU: MEV-P-C30-80

Part Number: MEV-P-C30-80

● In Stock

Catalogue-listed Dissmann MEV-P-C30-80: 80A AC690V/DC750V aR, DC10KA breaking capacity.

Rated Current80A

Rated VoltageAC690V/DC750V

Breaking CapacityDC10KA

PackageMEV-P-C C30

Tags

80A AC690V/DC750V aR Dissmann MEV-P-C MEV-P-C C30 MEV-P-C30-80

Dissmann MEV-P-C30-80 80A AC690V/DC750V aR Industrial Fuse

Breaking capacity: DC10KA; Catalogue requirements: UL248-13|ISO8820|JASO-D622|IEC60269; Catalogue marks/remarks: UL · RoHS; Package / format: MEV-P-C C30; Pre-arcing I²t: 380 A²s; Total I²t: 2550 A²s.

Confirm current, voltage, breaking capacity and installation requirements against the supplied Dissmann catalogue before final design-in.

Technical Specifications

Part Number: MEV-P-C30-80
Manufacturer Part Number: MEV-P-C30-80
Series: MEV-P-C Series
Fuse Type: Industrial Fuse
Current Rating: 80A
Voltage Rating: AC690V/DC750V
AC / DC: AC · DC
Breaking Capacity: DC10KA
Pre-arcing I²t: 380
Total I²t: 2550
Package / Dimensions: MEV-P-C C30
Mounting: Bolt-On
Standard: IEC60269 · ISO8820 · JASO D622 · UL248-13
Terminal Type: Bolt Lug
Utilization Class: aR
Approvals: RoHS · UL
Certifications: UL · RoHS
Reference Lead Time: 4–8 weeks
Minimum Order: 100 pcs
Sample Status: Sample available
