Dissmann

Dissmann MEV-H-H63-1250 1250A AC690V/DC500V aR Industrial Fuse

Name: Dissmann MEV-H-H63-1250 1250A AC690V/DC500V aR Industrial Fuse
Brand: Dissmann
SKU: MEV-H-H63-1250

Part Number: MEV-H-H63-1250

● Contact for Availability

Specify Dissmann MEV-H-H63-1250 for 1250A AC690V/DC500V protection; series MEV-H-H63, type aR.

Rated Current1250A

Rated VoltageAC690V/DC500V

Breaking CapacityDC10KA

PackageMEV-H-H63

Tags

1250A AC690V/DC500V aR Dissmann MEV-H-H63 MEV-H-H63-1250

Dissmann MEV-H-H63-1250 1250A AC690V/DC500V aR Industrial Fuse

Breaking capacity: DC10KA; Catalogue requirements: UL248-13|ISO8820|JASO-D622|IEC60269; Catalogue marks/remarks: RoHS; Package / format: MEV-H-H63; Pre-arcing I²t: 280000.0 A²s; Total I²t: 1900000.0 A²s; Catalogue power dissipation: 140 W.

Confirm current, voltage, breaking capacity and installation requirements against the supplied Dissmann catalogue before final design-in.

Technical Specifications

Part Number: MEV-H-H63-1250
Manufacturer Part Number: MEV-H-H63-1250
Series: MEV-H-H63 Series
Fuse Type: Industrial Fuse
Current Rating: 1250A
Voltage Rating: AC690V/DC500V
AC / DC: AC · DC
Breaking Capacity: DC10KA
Pre-arcing I²t: 280000
Total I²t: 1900000
Package / Dimensions: MEV-H-H63
Mounting: Bolt-On
Standard: IEC60269 · ISO8820 · JASO D622 · UL248-13
Terminal Type: Bolt Lug
Utilization Class: aR
Approvals: RoHS
Certifications: RoHS
Catalogue power dissipation: 140 W.
