Conquer R30-700 7.00A 30V DC Fuse
● Contact for AvailabilityUse Conquer R30-700 for 7.00A 30V DC circuit protection where a pptc resettable is required.
Rated Current7.00A
Rated Voltage30V DC
QUICK RFQ
Request a quote for R30-700
Submit directly from this product page. We will reply with availability, lead time and pricing.
Part NumberR30-700BrandConquerRequested Qty100
R30-700 is a Conquer R30 Series pptc resettable with 7.00A current rating and 30V DC voltage rating.
Ihold: 7.00A Itrip: 14.00A Imax: 40A PD: 3.80W Time-to-trip: 17.5s @ 35.00A Rmin–Rmax: 0.005–0.020Ω R1max: 0.030Ω; Mounting: Radial Through-Hole.
Select the fuse only after coordinating its current rating with normal operating load and expected transient conditions.
Technical Specifications
- Part Number
- R30-700
- Manufacturer Part Number
- R30-700
- Series
- R30 Series
- Fuse Type
- PPTC Resettable
- Current Rating
- 7.00A
- Voltage Rating
- 30V DC
- AC / DC
- DC
- Mounting
- Radial Through-Hole
- Reference Lead Time
- 4-6 weeks
- Minimum Order
- 100 pcs
- Sample Status
- Sample available
- Ihold
- 7.00A
- Itrip
- 14.00A
- Imax
- 40A
- PD
- 3.80W
- Time-to-trip
- 17.5s @ 35.00A
- Rmin–Rmax
- 0.005–0.020Ω
- R1max
- 0.030Ω
