Mersen TR12R 12A RK5 Time-Delay Fuse

Name: Mersen TR12R 12A RK5 Time-Delay Fuse
Brand: Mersen
SKU: TR12R

Part Number: TR12R

● Check availability

Specify Mersen TR12R as a 12A Class RK5 time-delay current-limiting fuse rated 250 VAC / 160 VDC. Its ferrule configuration is intended for motor and related protection work. Confirm compatibility with the intended fuse block or bus connection.

Rated Current12A

Rated Voltage250 VAC / 160 VDC

Breaking Capacity200 kA AC / 20 kA DC

PackageClass RK5 Ferrule

Tags

12A class rk5 current-limiting Ferrule Mersen TR-R TR12R

Specify Mersen TR12R for applications that call for a 12A Class RK5 time-delay current-limiting fuse with a 250 VAC / 160 VDC rating. The ferrule version is specified with 200 kA AC / 20 kA DC interrupting capability and is suited to motor, transformer, feeder, branch circuit, service entrance. Confirm compatibility with the intended fuse block or bus connection. FuseStock keeps the manufacturer reference and series data together for technical comparison and sourcing.

Technical Specifications

Part Number: TR12R
Manufacturer Part Number: TR12R
Series: TR-R Series
Fuse Type: Current-Limiting Fuse
Current Rating: 12A
Voltage Rating: 250 VAC / 160 VDC
AC / DC: AC/DC
Breaking Capacity: 200 kA AC / 20 kA DC
Package / Dimensions: Class RK5 Ferrule
Mounting: Cartridge / Clip · Fuse Block
Application: Branch Circuit Protection · Feeder circuits · Motor · Service entrance · Transformer
Standard: CSA C22.2 No. 248.12 · UL 248-12
Terminal Type: Ferrule
Fuse Speed: Time Delay
Utilization Class: Class RK5
Approvals: CSA · UL Listed
Certifications: UL Listed|CSA Certified
