Mersen CRS35 35A 600V Class H Time-Delay Fuse

Name: Mersen CRS35 35A 600V Class H Time-Delay Fuse
Brand: Mersen
SKU: CRS35

Part Number: CRS35

● Contact for Availability

For 35A circuit protection, CRS35 is a catalog member of Mersen’s CRS Series. The electrical profile is 600V AC, with 10kA AC published interrupting performance. This makes it suitable where Type D time-delay protection for circuits with temporary overloads and inrush.

Rated Current35A

Rated Voltage600V AC

Breaking Capacity10kA AC

PackageClass H/K

Tags

class h CRS Series CRS35 Mersen time-delay

Part CRS35 belongs to the Mersen CRS Series and is rated 35A. The published rating combines 600V AC operation and 10kA AC short-circuit capability. Its operating characteristic provides Type D time-delay protection for circuits with temporary overloads and inrush. The Class H format uses ferrule / blade (amp-dependent) terminals with cartridge/clip mounting. Typical selection contexts include Motor Circuits, Transformers, Lighting With High Inrush. Final application limits and dimensional details should be verified against Mersen’s official datasheet.

Technical Specifications

Part Number: CRS35
Manufacturer Part Number: CRS35
Series: CRS Series
Fuse Type: Type D Time-Delay Class H Fuse
Current Rating: 35A
Voltage Rating: 600V AC
AC / DC: AC
Breaking Capacity: 10kA AC
Package / Dimensions: Class H/K
Mounting: Cartridge / Clip
Application: High inrush · Industrial circuits · Motor Circuits · Solenoid · Transformers
Standard: CSA Type D / CSA C22.2 No. 248
Terminal Type: Ferrule / Blade (amp-dependent)
Fuse Speed: Time Delay
Utilization Class: Class H
Approvals: CSA Certified
Certifications: CSA Certified
