Littelfuse RLN004 4A 250V Class H Renewable Fuse

Name: Littelfuse RLN004 4A 250V Class H Renewable Fuse
Brand: Littelfuse
SKU: RLN004

Part Number: RLN004

● Contact for Availability

RLN004 is a 4A Class H renewable fuse from Littelfuse, rated 250V AC for feeder circuits, branch circuit protection and general purpose.

Rated Current4A

Rated Voltage250V AC

Breaking Capacity10kA AC

PackageClass H/K

Tags

250V 4A class h Littelfuse Renewable RLN Series RLN004

In the RLN Series family, Littelfuse RLN004 delivers 4A protection with a 250V AC rating. Its cartridge / clip form factor, Class H size and 10kA AC rating define the core installation limits. Applications include feeder circuits, branch circuit protection and general purpose; verify installation requirements against UL 248-6 and the listed UL Listed and CSA approvals. The manufacturer states that renewable Class H fuses should not be selected for new applications; verify short-circuit conditions and replacement practices in the datasheet.

Technical Specifications

Part Number: RLN004
Manufacturer Part Number: RLN004
Series: RLN Series
Fuse Type: Class H Renewable Fuse
Current Rating: 4A
Voltage Rating: 250V AC
AC / DC: AC
Breaking Capacity: 10kA AC
Package / Dimensions: Class H/K
Mounting: Cartridge / Clip
Application: Branch Circuit Protection · Feeder circuits · General purpose protection
Standard: UL 248-6
Terminal Type: Ferrule
Fuse Speed: Renewable
Utilization Class: Class H
Approvals: CSA · UL Listed
Certifications: UL Listed · CSA
Replacement fuse links: LKN Series
