Littelfuse KLK009 9A 600V Fast-Acting 10×38mm Midget Fuse

Name: Littelfuse KLK009 9A 600V Fast-Acting 10×38mm Midget Fuse
Brand: Littelfuse
SKU: KLK009

Part Number: KLK009

● Contact for Availability

Littelfuse KLK009 combines a 9A rating with fast-acting 10×38mm midget fuse; midget cartridge, with published series ratings and ordering-specific configuration.

Rated Current9A

Rated Voltage600 V AC / 500 V DC

Breaking Capacity100 kA @ 600 V AC; 50 kA @ 500 V DC

Package10×38mm

Tags

10×38mm Midget Fuse 9A KLK Series KLK009 Littelfuse midget cartridge

For designs centered on 9A overcurrent protection, KLK009 belongs to the Littelfuse KLK Series. The selected part uses midget cartridge. High-interrupting-capacity construction supports control, lighting and metering applications. Published ratings are 600 V AC / 500 V DC with 100 kA @ 600 V AC; 50 kA @ 500 V DC interrupting capacity. Verify ambient derating, coordination and the exact manufacturer ordering code against the current Littelfuse datasheet before design-in.

Technical Specifications

Part Number: KLK009
Manufacturer Part Number: KLK009
Series: KLK Series
Fuse Type: 10×38mm Midget Fuse
Current Rating: 9A
Voltage Rating: 600 V AC / 500 V DC
AC / DC: AC/DC
Breaking Capacity: 100 kA @ 600 V AC; 50 kA @ 500 V DC
Package / Dimensions: 10×38mm
Mounting: Cartridge / Clip · Fuse Holder
Application: Control circuits · HID ballasts · Meter circuits · Street lighting
Standard: UL/CSA supplemental fuse standards by rating
Terminal Type: Ferrule end caps
Fuse Speed: Fast Acting (F)
Utilization Class: Midget · Supplemental
Approvals: CSA · UL Listed
Certifications: UL Listed (E10480); CSA Certified (LR29862)
