Littelfuse KLK.100 0.1A 600V Fast-Acting 10×38mm Midget Fuse

Name: Littelfuse KLK.100 0.1A 600V Fast-Acting 10×38mm Midget Fuse
Brand: Littelfuse
SKU: KLK.100

Part Number: KLK.100

● Contact for Availability

Within the KLK Series, Littelfuse KLK.100 provides 0.1A protection; midget cartridge, with published series ratings and ordering-specific configuration.

Rated Current0.1A

Rated Voltage600 V AC / 500 V DC

Breaking Capacity100 kA @ 600 V AC; 50 kA @ 500 V DC

Package10×38mm

Tags

0.1A 10×38mm Midget Fuse KLK Series KLK.100 Littelfuse midget cartridge

KLK.100 is the 0.1A ordering option in the Littelfuse KLK Series, using fast-acting 10×38mm midget fuse construction. The selected part uses midget cartridge. High-interrupting-capacity construction supports control, lighting and metering applications. Published ratings are 600 V AC / 500 V DC with 100 kA @ 600 V AC; 50 kA @ 500 V DC interrupting capacity. Verify ambient derating, coordination and the exact manufacturer ordering code against the current Littelfuse datasheet before design-in.

Technical Specifications

Part Number: KLK.100
Manufacturer Part Number: KLK.100
Series: KLK Series
Fuse Type: 10×38mm Midget Fuse
Current Rating: 0.1A
Voltage Rating: 600 V AC / 500 V DC
AC / DC: AC/DC
Breaking Capacity: 100 kA @ 600 V AC; 50 kA @ 500 V DC
Package / Dimensions: 10×38mm
Mounting: Cartridge / Clip · Fuse Holder
Application: Control circuits · HID ballasts · Meter circuits · Street lighting
Standard: UL/CSA supplemental fuse standards by rating
Terminal Type: Ferrule end caps
Fuse Speed: Fast Acting (F)
Utilization Class: Midget · Supplemental
Approvals: CSA · UL Listed
Certifications: UL Listed (E10480); CSA Certified (LR29862)
