Littelfuse FLQ01.6 1.6A 500V Time-Delay Midget Fuse

Littelfuse

Littelfuse FLQ01.6 1.6A 500V Time-Delay Midget Fuse

Part Number: FLQ01.6

● Contact for Availability

This Littelfuse time-delay midget fuse, part FLQ01.6, is rated 1.6A/500V AC and uses a 10×38mm package.

Rated Current1.6A

Rated Voltage500V AC

Breaking Capacity10kA

Package10×38mm

Tags

1.6A 10×38mm 500V FLQ Series FLQ01.6 Littelfuse time-delay

In the FLQ Series family, Littelfuse FLQ01.6 delivers 1.6A protection with a 500V AC rating. It is built in a 10×38mm format for cartridge / clip mounting and is rated to interrupt 10kA. Typical applications include motor, transformer and control circuits; the product is listed to UL 248-14 with UL Listed, CSA, CE and RoHS approvals.

Technical Specifications

Part Number: FLQ01.6
Manufacturer Part Number: FLQ01.6
Series: FLQ Series
Fuse Type: Time-Delay Midget Fuse
Current Rating: 1.6A
Voltage Rating: 500V AC
AC / DC: AC
Breaking Capacity: 10kA
Package / Dimensions: 10×38mm
Mounting: Cartridge / Clip
Application: Control circuits · Motor · Transformer
Standard: UL 248-14
Terminal Type: Ferrule
Fuse Speed: Time Delay
Utilization Class: Supplemental
Approvals: CE · CSA · RoHS · UL Listed
Certifications: UL Listed · CSA · CE · RoHS
DC Voltage Rating: 300V DC
DC Interrupting Rating: 10kA (Littelfuse self-certified)

Downloads

DatasheetOpen / download →
