Part FLNR110ID is a 110A member of the Littelfuse FLNR_ID Series with a 250V AC / 125V DC rating. The device couples indicating Class RK5 fuse construction with a 200kA AC AC interrupting rating. Visual blown-fuse indication is part of the series design. Use the Littelfuse datasheet to verify final circuit suitability.
Submit directly from this product page. We will reply with availability, lead time and pricing.
FLNR110ID is Littelfuse’s 110A configuration in the FLNR_ID Series, built as a Indicating Dual-Element Time-Delay Class RK5 Fuse for 250V AC / 125V DC service. The fuse combines Class R construction, ferrule / blade (amp-dependent) termination and a 200kA AC primary interrupting specification. Published dimensions for this rating/configuration are 181.0mm length; 39.0mm max body diameter. The indicator window provides visual blown-fuse status to support faster troubleshooting. The listed application set includes Service Entrance, Transformer, Switchboard Mains, Motor Branch Circuits, general-purpose circuits; final coordination should follow UL 248-12 and Littelfuse documentation.
KLNR100
100A · 250V AC / 125V DC
KLNR080
80A · 250V AC / 125V DC
KLNR090
