Littelfuse FLM005 5A 250V Time-Delay Midget Fuse

Littelfuse

Littelfuse FLM005 5A 250V Time-Delay Midget Fuse

Part Number: FLM005

● Contact for Availability

FLM005 is a 5A time-delay midget fuse from Littelfuse, rated 250V AC for motor, transformer and control circuits.

Rated Current5A

Rated Voltage250V AC

Breaking Capacity10kA

Package10×38mm

Tags

10×38mm 250V 5A FLM Series FLM005 Littelfuse time-delay

Rated 5A at 250V AC, Littelfuse FLM005 is a time-delay midget fuse in the FLM Series. The 10×38mm format measures 38.1 × 10.31mm and uses ferrule terminations; interrupting capacity is 10kA. Typical applications include motor, transformer and control circuits; the product is listed to UL 248-14 with UL Listed, CSA, CE and RoHS approvals.

Technical Specifications

Part Number: FLM005
Manufacturer Part Number: FLM005
Series: FLM Series
Fuse Type: Time-Delay Midget Fuse
Current Rating: 5A
Voltage Rating: 250V AC
AC / DC: AC
Breaking Capacity: 10kA
Package / Dimensions: 10×38mm
Mounting: Cartridge / Clip
Application: Control circuits · Motor · Transformer
Standard: UL 248-14
Terminal Type: Ferrule
Fuse Speed: Time Delay
Utilization Class: Supplemental
Approvals: CE · CSA · RoHS · UL Listed
Certifications: UL Listed · CSA · CE · RoHS
DC Voltage Rating: 125V DC
DC Interrupting Rating: 10kA (Littelfuse self-certified)
Body: Paper

Downloads

DatasheetOpen / download →
