Littelfuse BLS010 10A 250V Fast-Acting 10×35mm Fuse

Name: Littelfuse BLS010 10A 250V Fast-Acting 10×35mm Fuse
Brand: Littelfuse
SKU: BLS010

Part Number: BLS010

● Contact for Availability

For a 10A 250V fuse requirement, Littelfuse BLS010 provides 250V AC protection with fast-acting characteristics for street lighting, metering and control circuits.

Rated Current10A

Rated Voltage250V AC

Breaking Capacity10kA

Package10×35mm

Tags

10×35mm 10A 250V BLS Series BLS010 fast acting (f)Littelfuse

The BLS Series BLS010 is a Littelfuse fast-acting midget fuse for 10A, 250V AC protection. Key construction details include 10×35mm, 34.9 × 10.31mm and ferrule terminals, plus a 10kA interrupting rating. For street lighting, metering and control circuits, confirm final circuit suitability using the datasheet, UL 248-14 and applicable UL Listed, CSA, RoHS and Lead Free marks.

Technical Specifications

Part Number: BLS010
Manufacturer Part Number: BLS010
Series: BLS Series
Fuse Type: Fast-Acting Midget Fuse
Current Rating: 10A
Voltage Rating: 250V AC
AC / DC: AC
Breaking Capacity: 10kA
Package / Dimensions: 10×35mm
Mounting: Cartridge / Clip
Application: Control circuits · Electronic Equipment Protection · Meter circuits · Street lighting
Standard: UL 248-14
Terminal Type: Ferrule
Fuse Speed: Fast Acting (F)
Utilization Class: Supplemental
Approvals: CSA · RoHS · UL Listed
Certifications: UL Listed · CSA · RoHS · Lead Free
Body: Paper
Cap: Nickel-plated bronze
