Littelfuse BLN025 25A 250V Fast-Acting 10×38mm Fuse
● Contact for AvailabilityLittelfuse BLN025 provides 25A/250V AC protection with fast-acting characteristics and 10kA interrupting capacity.
Rated Current25A
Rated Voltage250V AC
Breaking Capacity10kA
Package10×38mm
QUICK RFQ
Request a quote for BLN025
Submit directly from this product page. We will reply with availability, lead time and pricing.
Part NumberBLN025BrandLittelfuseRequested Qty100
Littelfuse’s BLN025 is a 25A fast-acting midget fuse rated for 250V AC operation. It is built in a 10×38mm format for cartridge / clip mounting and is rated to interrupt 10kA. For control circuits and military, confirm final circuit suitability using the datasheet, UL 248-14 and applicable UL Listed, CSA, PSE, CE, RoHS and QPL marks.
Technical Specifications
- Part Number
- BLN025
- Manufacturer Part Number
- BLN025
- Series
- BLN Series
- Fuse Type
- Fast-Acting Midget Fuse
- Current Rating
- 25A
- Voltage Rating
- 250V AC
- AC / DC
- AC
- Breaking Capacity
- 10kA
- Package / Dimensions
- 10×38mm
- Mounting
- Cartridge / Clip
- Application
- Control circuits · Military
- Standard
- UL 248-14
- Terminal Type
- Ferrule
- Fuse Speed
- Fast Acting (F)
- Utilization Class
- Supplemental
- Approvals
- CE · CSA · RoHS · UL Listed
- Certifications
- UL Listed · CSA · PSE · CE · RoHS · QPL
- Body
- Paper
- Cap
- Nickel-plated bronze
- QPL
- MIL-F-15160/9
Downloads
Mersen SLR9 9A 300VAC fast-acting in-line fuse
SLR9
9A · 300VAC
Mersen SLR8 8A 300VAC fast-acting in-line fuse
SLR8
8A · 300VAC
Mersen SLR7 7A 300VAC fast-acting in-line fuse
SLR7
7A · 300VAC
Mersen SLR6 6A 300VAC fast-acting in-line fuse
SLR6
6A · 300VAC
Mersen SLR5 5A 300VAC fast-acting in-line fuse
