Littelfuse 39212000000 2A 250V TE5 Time-Lag PCB Fuse

Name: Littelfuse 39212000000 2A 250V TE5 Time-Lag PCB Fuse
Brand: Littelfuse
SKU: 39212000000

Part Number: 39212000000

● Contact for Availability

Littelfuse 39212000000, 2A time-lag TE5 radial PCB fuse, 250 V AC; standard long-lead tape/ammopack configuration with nominal melting I²t 29 A²s.

Rated Current2A

Rated Voltage250 V AC

Breaking Capacity35 A @ 250 VAC (IEC); 130 A @ 250 VAC (UL)

PackageTE5 Radial

Tags

0000 standard long-lead tape/ammopack configuration 2A 392 Series 39212000000 Littelfuse TE5 Time-Lag

Littelfuse 39212000000 combines a 2 A rating, time-lag response and TE5 radial PCB fuse construction in the 392 Series family. The selected ordering variant is the standard long-lead tape/ammopack configuration. Electrical data includes 35 A @ 250 VAC (IEC); 130 A @ 250 VAC (UL) interrupting capability and 29 A²s nominal melting I²t. For substitution or design-in, compare the exact package code, ambient derating and time-current behavior with the official datasheet.

Technical Specifications

Part Number: 39212000000
Manufacturer Part Number: 39212000000
Series: 392 Series
Fuse Type: TE5 Radial PCB Fuse
Current Rating: 2A
Voltage Rating: 250 V AC
AC / DC: AC
Breaking Capacity: 35 A @ 250 VAC (IEC); 130 A @ 250 VAC (UL)
I²t: 29 A²s nominal melting I²t
Pre-arcing I²t: 29
Operating Temperature: -40°C to +125°C
Package / Dimensions: TE5 Radial
Mounting: PCB Through-Hole
Application: Power Electronics
Standard: IEC 60127-3 · UL 248-14
Terminal Type: Tin-plated copper long radial leads
Fuse Speed: Time Delay
Approvals: CE · RoHS · UL Recognized · VDE
Certifications: UL Recognized; CE; VDE; RoHS
Package/configuration: Tape/Ammopack. Nominal melting I²t: 29 A²s. Radial subminiature body; 5.08 mm lead pitch. Verify exact lead dimensions in the official datasheet.
