Littelfuse 38211600410 1.6A 250V TR5 Time-Lag PCB Fuse

Name: Littelfuse 38211600410 1.6A 250V TR5 Time-Lag PCB Fuse
Brand: Littelfuse
SKU: 38211600410

Part Number: 38211600410

● Contact for Availability

38211600410 is a 1.6A Littelfuse TR5 radial PCB fuse with time-lag response, 250 V AC rating and short-lead bulk configuration.

Rated Current1.6A

Rated Voltage250 V AC

Breaking Capacity100 A @ 250 VAC

PackageTR5 Radial

Tags

0410 short-lead bulk configuration 1.6A 382 Series 38211600410 Littelfuse Time-Lag TR5

For circuit protection requiring a 1.6 A time-lag device, 38211600410 is the short-lead bulk configuration of Littelfuse 382 Series. The TR5 radial PCB fuse is rated 250 V AC, with published interrupting capability of 100 A @ 250 VAC and nominal melting I²t of 12.67 A²s. Package and lead details are part-number specific, so retain the full ordering code and validate coordination using the Littelfuse curves.

Technical Specifications

Part Number: 38211600410
Manufacturer Part Number: 38211600410
Series: 382 Series
Fuse Type: TR5 Radial PCB Fuse
Current Rating: 1.6A
Voltage Rating: 250 V AC
AC / DC: AC
Breaking Capacity: 100 A @ 250 VAC
I²t: 12.67 A²s nominal melting I²t
Pre-arcing I²t: 12.67
Operating Temperature: -40°C to +85°C
Package / Dimensions: TR5 Radial
Mounting: PCB Through-Hole
Application: Power Electronics
Standard: IEC 60127-3 · UL 248-14
Terminal Type: Tin-plated copper short radial leads
Fuse Speed: Time Delay
Approvals: CCC · CE · RoHS · UL Recognized · VDE
Certifications: UL Recognized; CE; VDE; CCC; RoHS
Package/configuration: Short-lead bulk, 1000 pcs. Nominal melting I²t: 12.67 A²s. Radial subminiature body; 5.08 mm lead pitch. Verify exact lead dimensions in the official datasheet.
