Littelfuse

Littelfuse 37312000410 2A 250V TR5 Fast-Acting PCB Fuse

Name: Littelfuse 37312000410 2A 250V TR5 Fast-Acting PCB Fuse
Brand: Littelfuse
SKU: 37312000410

Part Number: 37312000410

● Contact for Availability

Order code 37312000410: 2A fast-acting Littelfuse 373 Series TR5 radial PCB fuse, supplied as the short-lead bulk configuration.

Rated Current2A

Rated Voltage250 V AC

Breaking Capacity50 A @ 250 VAC

PackageTR5 Radial

Tags

0410 short-lead bulk configuration 2A 373 Series 37312000410 fast acting Littelfuse TR5

Littelfuse part 37312000410 identifies a short-lead bulk configuration within the 373 Series TR5 radial PCB fuse range. Key ratings are 2 A, 250 V AC, fast-acting operation, 50 A @ 250 VAC interrupting capability and 0.63 A²s nominal melting I²t. This page is keyed to the exact orderable variant rather than only the base series; check the latest datasheet for final circuit-protection selection.

Technical Specifications

Part Number: 37312000410
Manufacturer Part Number: 37312000410
Series: 373 Series
Fuse Type: TR5 Radial PCB Fuse
Current Rating: 2A
Voltage Rating: 250 V AC
AC / DC: AC
Breaking Capacity: 50 A @ 250 VAC
I²t: 0.63 A²s nominal melting I²t
Pre-arcing I²t: 0.63
Operating Temperature: -40°C to +85°C
Package / Dimensions: TR5 Radial
Mounting: PCB Through-Hole
Application: Power Electronics
Standard: UL 248-14
Terminal Type: Tin-plated copper short radial leads
Fuse Speed: Fast Acting (F)
Approvals: CSA · RoHS · UL Recognized
Certifications: UL Recognized; CSA; RoHS
Package/configuration: Short-lead bulk, 1000 pcs. Nominal melting I²t: 0.63 A²s. Radial subminiature body; 5.08 mm lead pitch. Verify exact lead dimensions in the official datasheet.
