Littelfuse 045106.3NRSN 6.3A 125V Very Fast-Acting NANO² SMD Fuse
● Contact for Availability045106.3NRSN is a 6.3A NANO² very fast-acting SMD fuse from Littelfuse, rated 125V AC/DC for power electronics, telecom dc and battery charging.
Rated Current6.3A
Rated Voltage125V AC/DC
Breaking Capacity50A @125VAC/VDC
PackageSMD 2410
QUICK RFQ
Request a quote for 045106.3NRSN
Submit directly from this product page. We will reply with availability, lead time and pricing.
Part Number045106.3NRSNBrandLittelfuseRequested Qty100
Rated 6.3A at 125V AC/DC, Littelfuse 045106.3NRSN is a NANO² very fast-acting SMD fuse in the 451 Series. The device uses end cap terminals in a SMD 2410 body and carries a 50A @125VAC/VDC interrupting rating. This part is cataloged for power electronics, telecom dc and battery charging and carries CE, UKCA, RoHS and Halogen Free; UL/CSA/PSE approvals vary by ampere rating approvals under UL 248-14|IEC 60127-7. Listed I²t: Nominal melting: 9.17 A²s.
Technical Specifications
- Part Number
- 045106.3NRSN
- Manufacturer Part Number
- 045106.3NRSN
- Series
- 451 Series
- Fuse Type
- NANO² Very Fast-Acting SMD Fuse
- Current Rating
- 6.3A
- Voltage Rating
- 125V AC/DC
- AC / DC
- AC/DC
- Breaking Capacity
- 50A @125VAC/VDC
- I²t
- Nominal melting: 9.17 A²s
- Pre-arcing I²t
- 9.17
- Operating Temperature
- -55°C to +125°C
- Package / Dimensions
- SMD 2410
- Mounting
- SMD
- Application
- Battery chargers · Power Electronics · Telecom DC distribution
- Standard
- IEC 60127-7 · UL 248-14
- Terminal Type
- End Cap
- Fuse Speed
- Very Fast Acting
- Utilization Class
- Supplemental
- Approvals
- CE · RoHS
- Certifications
- CE · UKCA · RoHS · Halogen Free; UL/CSA/PSE approvals vary by ampere rating
- Body
- Ceramic
- Packaging
- 5000 pcs Tape & Reel
- Moisture Sensitivity Level
- 1
- Nominal melting I²t
- 9.17 A²s
